Datos del producto:
|
| Protección de ingreso: | IP65 | Uso: | Equipo de batería de succión |
|---|---|---|---|
| Fuerza: | 12W | Humedad relativa: | 20%-85% |
| Alto voltaje: | CA700V.3mA/s | Rango de temperatura: | -20°C~+65°C, 5%~95% de H.R. |
| Vida útil eléctrica: | 300000 | Forma: | Cilíndrico |
| Estructura: | Tubular | Especificación y tamaño: | 07*34 (milímetro) |
| Ciclo de funcionamiento: | 0.5 segundos encendido, 5 segundos apagado | Vida útil: | 500 mil veces |
| Deber: | 100% | Ataque: | 10 mm |
| Solicitud: | Automatización industrial |
Push Pull Solenoid TU4875 Powerful 80N Force Long Stroke 0-30mm Electromagnet Solenoid
| Specification | |||
| Brand | Dason | Product Name | Push Pull Solenoid |
| Model | TU4875 | Voltage | DC 12v 24v |
| Power | 17-170W | Force | 0-80N |
| Waterproof Class | IP65 | Duty Cycle | 10%-100% |
| Cable Length | 200mm | Material | Metal. Electronic Parts |
| Action Form | Screw | Stroke(mm) | 0-30mm |
| Hi-Pot Test | AC 600V 50/60 Hz 2s | Insulation Class | B |
| Packaging Details | |||
| Body Size | L75*D48 (mm) | Carton Size(Standard) | 35*31*18(cm), accept custom |
TUBULAR SOLENOID
1. Push or pull type, tubular shape, dedium size, IP65 waterproof, DC 12v 24v standard voltage also accept custom.
2. The mini round solenoid need to be energized to develop force and de-energized to stop, widely used for lock, push things out or pull woeking part back and etc.
| Our Product | circular holding electromagnet, square holding electromagnet, open frame solenoid, tubular solenoid, keep solenoid, electromagnet lock, solneoid lock |
| MOQ | 2 pcs, small orders can be acceptable if we have stocks of this product |
| Packaging | carton, standard dimension(L*W*H): 35*31*18 CM, suctomize according yo customer's requirement |
| Delivery Time | shipped in 5-20 days after payment (decided by the order quantity and stock) |
| Supply Ability | 5000 pcs per month |
| Payment Terms | T/T, paypal, etc. |
| Shipping | sea freight, air freight, express (DHL, UPS, FEDEX, EMS and etc. ) |
